# pak::pak("ddsjoberg/gtsummary")
library(gtsummary)
tbl_summary_ex <-
trial %>%
select(trt, age, grade, response) %>%
tbl_summary(by = trt)
tbl_regression_ex <-
lm(age ~ grade + marker, trial) %>%
tbl_regression() %>%
bold_p(t = 0.5){gtsummary} objects
Inside gtsummary objects
Every {gtsummary} table has a few characteristics common among all tables created with the package. Here, we review those characteristics, and provide instructions on how to construct a {gtsummary} object.
Let’s begin by creating two common gtsummary tables: a simple summary and a regression model summary.
Structure of a {gtsummary} object
Every {gtsummary} object is a list comprising of, at minimum, these elements:
.$table_body .$table_styling table_body is a data frame of the table to be printed, and table_styling are the instructions on how to style the print.
We now include an .$cards object internally. This is used to construct .$table_body.
table_body
The .$table_body object is the data frame that will ultimately be printed as the output. The table must include columns "label", "row_type", and "variable". The "label" column is printed, and the other two are hidden from the final output.
tbl_summary_ex$table_body# A tibble: 8 × 7
variable var_type row_type var_label label stat_1 stat_2
<chr> <chr> <chr> <chr> <chr> <chr> <chr>
1 age continuous label Age Age 46 (37, 60) 48 (3…
2 age continuous missing Age Unknown 7 4
3 grade categorical label Grade Grade <NA> <NA>
4 grade categorical level Grade I 35 (36%) 33 (3…
5 grade categorical level Grade II 32 (33%) 36 (3…
6 grade categorical level Grade III 31 (32%) 33 (3…
7 response dichotomous label Tumor Response Tumor Response 28 (29%) 33 (3…
8 response dichotomous missing Tumor Response Unknown 3 4 table_styling
The .$table_styling object is a list of data frames containing information about how .$table_body is printed, formatted, and styled.
The list contains the following data frames header, footnote, footnote_abbrev, fmt_fun, indent, text_format, fmt_missing, cols_merge and the following objects source_note, caption, horizontal_line_above.
header
The header table has the following columns and is one row per column found in .$table_body. The table contains styling information that applies to entire column or the columns headers.
| Column | Description |
|---|---|
column |
Column name from |
hide |
Logical indicating whether the column is hidden in the output. This column is also scoped in |
align |
Specifies the alignment/justification of the column, e.g. ‘center’ or ‘left’ |
label |
Label that will be displayed (if column is displayed in output) |
interpret_label |
the {gt} function that is used to interpret the column label, |
spanning_header |
Includes text printed above columns as spanning headers. |
interpret_spanning_header |
the {gt} function that is used to interpret the column spanning headers, |
modify_stat_{*} |
any column beginning with |
footnote & footnote_abbrev
NOTE: This is a description of the current state. I think this needs some modifications in the near future, e.g. allow more than one footnote per cell, abbreviations should not be footnotes, and be handled more like source notes, etc.
Each {gtsummary} table may contain a single footnote per header and cell within the table. Footnotes and footnote abbreviations are handled separately. Updates/changes to footnote are appended to the bottom of the tibble. A footnote of NA_character_ deletes an existing footnote.
| Column | Description |
|---|---|
column |
Column name from |
rows |
expression selecting rows in |
footnote |
string containing footnote to add to column/row |
fmt_fun
Numeric columns/rows are styled with the functions stored in fmt_fun. Updates/changes to styling functions are appended to the bottom of the tibble.
| Column | Description |
|---|---|
column |
Column name from |
rows |
expression selecting rows in |
fmt_fun |
list of formatting/styling functions |
indent
Instructions on which columns and rows to indent. Updates/changes to styling functions are appended to the bottom of the tibble.
| Column | Description |
|---|---|
column |
Column name from |
rows |
expression selecting rows in |
n_spaces |
integer indeicating teh number of spaces to indent |
text_format
Columns/rows are styled with bold, italic, or indenting stored in text_format. Updates/changes to styling functions are appended to the bottom of the tibble.
| Column | Description |
|---|---|
column |
Column name from |
rows |
expression selecting rows in |
format_type |
one of |
undo_text_format |
logical indicating where the formatting indicated should be undone/removed. |
fmt_missing
By default, all NA values are shown blanks. Missing values in columns/rows are replaced with the symbol. For example, reference rows in tbl_regression() are shown with an em-dash. Updates/changes to styling functions are appended to the bottom of the tibble.
| Column | Description |
|---|---|
column |
Column name from |
rows |
expression selecting rows in |
symbol |
string to replace missing values with, e.g. an em-dash |
cols_merge
This object is experimental and may change in the future. This tibble gives instructions for merging columns into a single column. The implementation in as_gt() will be updated after gt::cols_label() gains a rows= argument.
| Column | Description |
|---|---|
column |
Column name from |
rows |
expression selecting rows in |
pattern |
glue pattern directing how to combine/merge columns. The merged columns will replace the column indicated in ‘column’. |
source_note
String that is made a table source note. The attribute "text_interpret" is either c("md", "html").
caption
String that is made into the table caption. The attribute "text_interpret" is either c("md", "html").
horizontal_line_above
Expression identifying a row where a horizontal line is placed above in the table.
Example from tbl_regression()
tbl_regression_ex$table_styling$header
# A tibble: 24 × 8
column hide align interpret_label label interpret_spanning_h…¹
<chr> <lgl> <chr> <chr> <chr> <chr>
1 variable TRUE center gt::md varia… gt::md
2 var_label TRUE center gt::md var_l… gt::md
3 var_type TRUE center gt::md var_t… gt::md
4 reference_row TRUE center gt::md refer… gt::md
5 row_type TRUE center gt::md row_t… gt::md
6 header_row TRUE center gt::md heade… gt::md
7 N_obs TRUE center gt::md N_obs gt::md
8 N TRUE center gt::md **N** gt::md
9 coefficients_type TRUE center gt::md coeff… gt::md
10 coefficients_label TRUE center gt::md coeff… gt::md
# ℹ 14 more rows
# ℹ abbreviated name: ¹interpret_spanning_header
# ℹ 2 more variables: spanning_header <chr>, modify_stat_N <int>
$footnote
# A tibble: 0 × 4
# ℹ 4 variables: column <chr>, rows <list>, text_interpret <chr>,
# footnote <chr>
$footnote_abbrev
# A tibble: 2 × 4
column rows text_interpret footnote
<chr> <list> <chr> <chr>
1 conf.low <quosure> gt::md CI = Confidence Interval
2 std.error <quosure> gt::md SE = Standard Error
$text_format
# A tibble: 1 × 4
column rows format_type undo_text_format
<chr> <list> <chr> <lgl>
1 p.value <quosure> bold FALSE
$indent
# A tibble: 2 × 3
column rows n_spaces
<chr> <list> <int>
1 label <lgl [1]> 0
2 label <quosure> 4
$fmt_missing
# A tibble: 4 × 3
column rows symbol
<chr> <list> <chr>
1 estimate <quosure> —
2 conf.low <quosure> —
3 std.error <quosure> —
4 statistic <quosure> —
$fmt_fun
# A tibble: 10 × 3
column rows fmt_fun
<chr> <list> <list>
1 estimate <quosure> <fn>
2 N <quosure> <fn>
3 N_obs <quosure> <fn>
4 n_obs <quosure> <fn>
5 conf.low <quosure> <fn>
6 conf.high <quosure> <fn>
7 p.value <quosure> <fn>
8 std.error <quosure> <fn>
9 statistic <quosure> <fn>
10 var_nlevels <quosure> <fn>
$cols_merge
# A tibble: 1 × 3
column rows pattern
<chr> <list> <chr>
1 conf.low <quosure> {conf.low}, {conf.high}Printing a {gtsummary} object
All {gtsummary} objects are printed with print.gtsummary(). Before a {gtsummary} object is printed, it is converted to a {gt} object using as_gt(). This function takes the {gtsummary} object as its input, and uses the information in .$table_styling to construct a list of {gt} calls that will be executed on .$table_body. After the {gtsummary} object is converted to {gt}, it is then printed as any other {gt} object.
The package can also utilize other print engines, such as flextable (as_flex_table()), huxtable (as_hux_table()), kableExtra (as_kable_extra()), kable (as_kable()), and tibbles/data frames (as_tibble()/as.data.frame()). The default print engine is set with the theme element "pkgwide-str:print_engine"
While the actual print function is slightly more involved, it is basically this:
print.gtsummary <- function(x, print_engine) {
switch(
print_engine,
"gt" = as_gt(x),
"flextable" = as_flex_table(x),
"huxtable" = as_hux_table(x),
"kable_extra" = as_kable_extra(x),
"kable" = as_kable(x)
) |>
print()
}
